How to connect servo motor to reducer

Release Time：

2024-09-25

Servo motor reducers are mostly installed on stepper motors, servo motors, or brushless motors to reduce speed and increase torque. In order to improve the matching inertia, the torque servo motor will be equipped with a reducer. When the load is large, blindly increasing the power of the servo motor is not cost-effective. Therefore, in order to use the switch power supply reasonably, it is necessary to choose a suitable reduction ratio servo reducer within the speed range. The servo reducer itself is designed to reduce speed and increase output torque.

Method of connecting servo motor to reducer:

Connected through an external coupling. Due to the need for servo electricity and key slots, this connection method uses an external coupling. External couplings can also use flexible couplings (flexible shafts) - the driving power of the flexible shaft generally does not exceed 5.5KW, and the speed can reach 20000 revolutions per minute.

2. Gripping method - The output shaft of the servo motor extends into the reducer, and the servo motor is connected to the reducer through a flange. There is a deformable clamp in the reducer. Operate the locking screw on the reducer to tightly grip the shaft of the servo motor.
