Scope of application of hard tooth surface reducer

Release Time：

2025-04-24

Hard tooth surface reducers are widely used in metallurgy, mining, lifting, transportation, cement, construction, chemical, textile, printing and dyeing, pharmaceutical and other fields.

Scope of application of hard tooth surface reducer
Hard tooth surface reducers are widely used in metallurgy, mining, lifting, transportation, cement, construction, chemical, textile, printing and dyeing, pharmaceutical and other fields.

1. The high-speed shaft speed shall not exceed 1500 revolutions per minute.

2. The circumferential speed of gear transmission shall not exceed 20 meters per second.

3. The working environment temperature is -40~45 ℃,

If it is below 0 ℃,

Before starting, the lubricating oil should be preheated to above 0 ℃,

This reducer can be used for both forward and reverse operation.

Characteristics of Hard Gear Reducer Products

1. The gears are made of high-strength low-carbon alloy steel that has been carburized and quenched,

The tooth surface hardness reaches HRC58-62,

The gears are all processed using grinding technology,

High precision and good contact.

2. High transmission efficiency: the third level is greater than 90%.

3. Smooth operation and low noise.

4. Small size and light weight,

Long service life and high load-bearing capacity.

5. Easy to disassemble and inspect, easy to install.
